Proximitor Seismic Monitor; 3500/42M; PWA 176449-02V; Monitor Module (Main Board); Consists PN: 176449-02 3500/42M Prox/SEIS Monitor; 128240-01 SEISMO I/O module w EXT TERM; 128015-08 Prox/Velom ET Block - Term; 128710-01 Recorder External Termination

Proximitor Seismic Monitor; 3500/42M; PWA 176449-02V; Monitor Module (Main Board); Consists PN: 176449-02 3500/42M Prox/SEIS Monitor; 128240-01 SEISMO I/O module w EXT TERM; 128015-08 Prox/Velom ET Block - Term; 128710-01 Recorder External Termination Block ANALYZER

MODEL: 3500/42M

PART NUMBER: PWA 176449-02V

TYPE: Monitor Module (Main Board)

ACCESSORIES: None ACCESSORIES

CONNECTION, PROCESS: Rack Type

CONNECTION,ELECTRICAL: Rack Type

CONSTRUCTION: Vibration

CURRENT RATING: +4 to +20 mA mA

DETECTION METHOD: from proximity and seismic transducers

EQUIPMENT/PACKAGE: N/A

EXPLOSION PROOF: None EXPLOSION PROOF

FREQUENCY RATING: 10 to 30,000 Hz Hz

HOUSING ENCLOSURE: N/A

INPUT: Accepts from 1 to 4 proximity, velocity or acceleration transducer signals

MATERIAL: Case: Aluminium

OUTPUT: 550 Ω Ohm

POWER SUPPLY: 7.7 W

PRESSURE RATING: None Pressure

RANGE: +4 to +20 mA

RANGE, INPUT SIGNAL: Accepts from 1 to 4 proximity, velocity or acceleration transducer signals

SIZE: 241.3 mm x 24.4 mm x 241.8 mm mm

TEMPERATURE RATING: -30°C to +65°C deg C

VOLTAGE RATING: 0 to +12 Vdc range across load

MANUFACTUER: Bently Nevada

APPLICATION: Feed Water Pump

ADDITIONAL INFORMATION: Consists PN: 176449-02 3500/42M Prox/SEIS Monitor; 128240-01 SEISMO I/O module w EXT TERM; 128015-08 Prox/Velom ET Block - Term; 128710-01 Recorder External Termination Block
